1 |
Sensor |
Electrochemical fuel cell |
2 |
Measuring Range |
00mg/100 ml to 500mg/100ml or 0.00 to 0.5BAC% |
3 |
Accuracy |
+/-2% at 80mg/100ml or +/-0.004BAC% at 0.16BAC % |
4 |
Units of measurement |
BAC, Mg/100ml |
5 |
Error Detection |
Blow Error and Wrong sampling detection |
6 |
Sampling system |
Deep lung Air for both active or passive <6 seconds |
7 |
Sampling modes |
Passive and active mode supported. |
8 |
Response time |
Less than 10 second |
9 |
Calibration |
Once in 6 months |
10 |
Display |
5 inch Full color display with Capacitive Touch screen and 2 Keys (power button and paper feed button) |
11 |
Camera |
5 Mega Pixel with 72° angle. |
12 |
Network / GPS |
3G / Built in GPS ±5-immune to RF |
13 |
Memory |
>50000 Memory with Photo, date, time, alcohol Content. Memory is not erased even if the power is switched OFF. |
14 |
Printer |
In Built Thermal printer that prints Alcohol Content, Photo, Serial Number, Date, Time and Calibration date. Facility to feed Drivers name, License No, Registration No, Mobile No, Address, Officer Name and Place and also GPS location details. |
15 |
Battery |
Built in rechargeable LI-Ion battery (7.4V 4000mAh) to take 250 Printouts minimum
|
16 |
Battery life |
More than 250 units one single charge and >400 tests printing and power off when not in use. |
17 |
Operating temperature* |
-5 to 55 Degree Celsius |
18 |
Blow pipe |
Disposable Straw (2000 Straws supplied with Each Analyzer) and Mouth piece (50nos) |
19 |
Paper rolls |
One with unit and 3extra provided. |
20 |
Installation software |
Software to download data to PC through USB port (Software customized as per requirement) |
21 |
Approval |
ETDC Approved |
22 |
Accessories |
Pouch for Instrument with belt and USB cable, Mains charger and car charger provided. |
|
|
|
